Units Conversion
English (USA) Unit X
Multiply by
= Metric Unit
X Multiply by
= English (USA) Unit

Linear Measure
in
25.40
mm
0.0394
in
Linear Measure
in
0.0254
m
39.37
in

ft
304.8
mm
0.0033
ft

ft
0.3048
m
3.281
ft

Square Measure
in2
645.2
mm2
0.00155
in2
Square Measure
in2
0.000645
m2
1550.0
in2

ft2
92.903
mm2
0.00001
ft2

ft2
0.0929
m2
10.764
ft2

Cubic Measure
ft3
0.0283
m3
35.31
ft3
Cubic Measure
ft3
28.32
L
0.0353
ft3

Speed Rate
ft / s
18.29
m / min
0.0547
ft / s
Speed Rate
ft / min
0.3048
m / min
3.281
ft / min

Avoirdupois Weight
lb
0.4536
kg
2.205
lb
Avoirdupois Weight
lb / ft3
16.02
kg / m3
0.0624
lb / ft3

Bearing Capacity
lb
0.4536
kg
2.205
lb
Bearing Capacity
lb
4.448
Newton (N)
0.225
lb

kg
9.807
Newton (N)
0.102
kg

lb / ft
1.488
kg / m
0.672
lb / ft

lb / ft
14.59
N / m
0.0685
lb / ft

kg  m
9.807
N / m
0.102
kg  m

Torque
in  lb
11.52
kg  mm
0.0868
in  lb
Torque
in  lb
0.113
N  m
8.85
in  lb

kg  mm
9.81
N  mm
0.102
kg  mm

Rotate Inertia
in4
416.231
mm4
0.0000024
in4
Rotate Inertia
in4
41.62
cm4
0.024
in4

Pressure /Stress
lb / in2
0.0007
kg / mm2
1422
lb / in2
Pressure / Stress
lb / in2
0.0703
kg / cm2
14.22
lb / in2

lb / in2
0.00689
N / mm2
145.0
lb / in2

lb / in2
0.689
N / cm2
1.450
lb / in2

lb / ft2
4.882
kg / m2
0.205
lb / ft2

lb / ft2
47.88
N / m2
0.0209
lb / ft2

Power
HP
745.7
watt
0.00134
HP
Power
ft  lb / min
0.0226
watt
44.25
ft  lb / min

Temperature
°F
T C = ( °F  32 ) / 1.8
Temperature
Symbol of B D E F
Symbol
Unit

BS
Conveyor Belt Tensile Strength
Kg/M

BW
Belt Width
M

C Symbol Definition
D Symbol Definition

Symbol
Unit

DS
Shaft Deflection Ratio
mm

E Symbol Definition

Symbol
Unit

E
Shaft Elongation Rate
Gpa

F Symbol Definition

Symbol
Unit

FC
Friction Coefficient Between Belt Edge and Hold Down Strip


FBP
Friction Coefficient Between Carry Product and Belt Surface


FBW
Friction Coefficient of Belt Support Material


FA
Coefficient Amended


FS
Tensile Strength Coefficient Amended


FT
Conveyor Belt Temperature Coefficient Amended

Symbol of H I L M
Symbol
Unit

H
Elevation Conveyor incline altitude.
m
HP
Horsepower
HP
I Symbol Definition

Symbol
Unit

I
Moment Of Inertia
mm4
L Symbol Definition

Symbol
Unit

L
Conveyance Distance (Center Point From Drive Shaft To Idler Shaft)
M
LR
Return Way Straight Run Section Length
M
LP
Carry Way Straight Run Section Length
M
M Symbol Definition

Symbol
Unit

M
Spiral Conveyor Layer Level

MHP
Motor Horsepower
HP
Symbol of P R S
Symbol
Unit

PP
Product Accumulated Measure Area Percentage of Carry Way

R Symbol Definition

Symbol
Unit

R
Sprocket Radius
mm
RO
Outside Radius
mm
rpm
Revolutions Per Minute
rpm
S Symbol Definition

Symbol
Unit

SB
Interval Between Bearing
mm
SL
Shaft Total Loading
Kg
SW
Shaft Weight
Kg/M
Symbol of T V W
Symbol
Unit

TA
Conveyor Belt Unit Allowable Tension
Kg/M
TB
Conveyor Belt Unit Theory Tension
Kg/M
TL
Conveyor Belt Unit Catenary's Sag tension.
Kg/M
TN
Tension Of Section
kg/M
TS
Torque
Kg.mm
TW
Conveyor Belt Unit Total Tension
Kg/M
TWS
Particular Type Conveyor Belt Unit Total Tension
Kg/M
V Symbol Definition

Symbol
Unit

V
Conveyance Speed
M/min
VS
Theory Speed
M/min
W Symbol Definition

Symbol
Unit

WB
Conveyor Belt Unit Weight
Kg/M2
Wf
Accumulated Conveyance Friction Stress
Kg/M2
WP
Conveyor Belt Carry Product Unit Weight
Pusher And Bidirectional
For the pusher or bidirectional conveyor, the belt tension will be higher than the ordinary horizontal conveyor; therefore, the shafts at two ends are necessary to be considered as drive shafts and subsumed in the calculation. In general, it is approximate 2.2 times the experience factor to get the total belt tension.
FORMULA :
TWS = 2.2 TW = 2.2 TB X FA
TWS in this unit means the tension calculation of the bidirectional or pusher conveyor.
Turning Calculation
The tension calculation TWS of the turning conveyor is to calculate the accumulated tension. Therefore, the tension in every carrying section will affect the value of total tension. That means, the total tension is accumulated from the the beginning of the drive section in return way, along the return way to the idler section, and then pass through the carrying section to the drive section.
The design point in this unit is T0 that under the drive shaft. The value of T0 is equal to zero; we calculate every section from T0. For example, the first straight section in return way is from T0 to T1, and that means the accumulated tension of T1.
T2 is the accumulated tension of the turning position in the return way; in another word, it is the accumulated tension of T0, T1 and T2. Please according to the illustration above and figure out the accumulated tension of the latter sections.
FORMULA :
TWS = ( T6 )

Total tension of the drive section in the carrying way. TWS in this unit means the tension calculation of the turning conveyor.


FORMULA :
T0 = 0

T1 = WB + FBW X LR X WB

Tension of catenary sag at the drive position.


FORMULA :


Tension of the turning section in the return way.

For the value Ca and Cb, please refer to Table Fc.

T2 = ( Ca X T21 ) + ( Cb X FBW X RO ) X WB




FORMULA :
TN = TN1 + FBW X LR X WB

Tension of the straight section in the return way.

T3 = T31 + FBW X LR X WB

T3 = T2 + FBW X LR X WB


FORMULA :
TN = TN1 + FBW X LP X ( WB + WP )

Tension of the straight section in the carrying way.

T4 = T41 + FBW X LP X ( WB + WP )

T4 = T3 + FBW X LP X ( WB + WP )


FORMULA :
TN = ( Ca X TN1 ) + ( Cb X FBW X RO ) X ( WB + WP )

Tension of the turning section in the carrying way. For the value Ca and Cb, please refer to Table Fc.

T5 = ( Ca X T51 ) + ( Cb X FBW X RO ) X ( WB + WP )

T5 = ( Ca X T4 ) + ( Cb X FBW X RO ) X ( WB + WP )
Spiral Conveyor
FORMULA :
TWS = TB × FA
TWS in this unit means the tension calculation of spiral conveyor.
FORMULA :
TB = [ 2 × RO × M + ( L1 + L2 ) ] ( WP + 2WB ) × FBW + ( WP × H )
FORMULA :
TA = BS × FS × FT

Please refer to Table FT and Table FS.
Practical Example
The comparison of TA and TB, and other related calculations are the same as other types of conveyors. There are certain restrictions and regulations on the design and construction of the spiral conveyor. Therefore, while applying HONGSBELT spiral or turning belts to spiral conveyor system, we recommend you to refer to HONGSBELT Engineering manual and contact with our technical service department for further information and details.
Unit Tension
FORMULA :
TB = [ ( WP + 2WB ) X FBW ] X L + ( WP X H )
If carrying products are with the characteristic of piling up, the friction force Wf that increases during the piling up conveyance should be subsume to the calculation.
FORMULA :
TB = [ ( WP + 2WB ) X FBW + Wf ] X L + ( WP X H )
FORMULA :
Wf = WP X FBP X PP
Allowable Tension
Due to the different material of belt has different tensile strength that will be affected by temperature variation. Therefore, the calculation of unit allowable tension TA can be used to contrast with the belt total tension TW. This calculation result will help you to make the right choice of belt selection and match the demands of the conveyor. Please refer to Table FS and Table Ts in left menu.
FORMULA :
TA = BS X FS X FT

BS = Conveyor Belt Tensile Strength ( Kg / M )

FS and FT Refer to Table FS and Table FT
Table Fs
Series HS100
Series HS200
Series HS300
Series HS400
Series HS500
Table Ts
Acetal
Nylon
Polyethylene
Polypropylene
Shaft Selection
FORMULA :
SL = ( TW + SW ) ?BW
Driven / Idler Shaft Weight Table  SW
Shaft Dimensions
Shaft Weight ( Kg/M )

Carbon Steel
Stainless Steel
Aluminum Alloy

Square shaft
38mm
11.33
11.48
3.94
50mm
19.62
19.87
6.82

Round Shaft
30mm?/FONT>
5.54
5.62
1.93
45mm?/FONT>
12.48
12.64
4.34
Deflection of Drive / Idler Shaft  DS
Without Intermediate Bearing
FORMULA :
DS = 5 ?104 ( SL ?SB3 / E ?/FONT> I )
With Intermediate Bearing
FORMULA :
DS = 1 ?104 ( SL ?SB3 / E ?I )
Elasticity of Drive Shaft  E
Unit : Kg/mm2

Material
Stainless Steel
Carbon Steel
Aluminum Alloy
Drive Shaft Elastic Rate
19700
21100
7000
Inertia Moment  I
Bore diameter of drive sprocket
Inertia moment of shaft ( mm4 )

Square Shaft
38mm
174817
50mm
1352750

Round Shaft
30mm?/FONT>
40791
45mm?/FONT>
326741
Drive Shaft Torque Calculation  TS
FORMULA :
TS = TW ?BW ?R
For the calculation value above, please compare with the table below for selecting the best drive shaft. If the torque of the drive shaft is still too strong, the smaller sprocket can be used to reduce the torque, and also economize the prime cost of shaft and bearing.
Using the smaller sprocket to fit the drive shaft that with the bigger diameter to reduce the torque, or using the bigger sprocket to fit the drive shaft that with the smaller diameter to increase torque.
Maximum Torque Factor for Drive Shaft
Torque
Material
Journal Diameter (mm)

50
45
40
35
30
25
20

Kgmm x 1000
Stainless Steel
180
135
90
68
45
28
12
Carbon Steel
127
85
58
45
28
17
10

Aluminum Alloy



28
17
12
5
Horsepower
If the drive motor is selected for a gear reducer motor, the horsepower ratio should be greater than the carrying products and the total tensile force that generates during the belt running.
Horse Power (HP)
FORMULA :
= 2.2 × 104 × TW × BW × V

= Watts × 0.00134
Watts
FORMULA :
= ( TW × BW × V ) / ( 6.12 × R )

= ( TS × V ) / ( 6.12 × R )

= HP × 745.7
Table FC
Rail Material
Temperature
FC

Belt Material
Dry
Wet

HDPE / UHMW
10°C ~ 80°C
P.P.
0.10
0.10
P.E.
0.30
0.20

Actel
0.10
0.10

Nylon
0.35
0.25

Acetal
10°C ~ 100°C
P.P.
0.10
0.10
P.E.
0.10
0.10

Actel
0.10
0.10

Nylon
0.20
0.20
Please contrast the rails material and belt material of the conveyor with the transporting procedure in dry or wet environment to get value FC.
Ca, Cb Value
Conveyor Belt Turning Angle
Friction Coefficient Between Conveyor Belt Edge & Rail Strip

FC ≤ 0.15
FC ≤ 0.2
FC ≤ 0.3

Ca
Cb
Ca
Cb
Ca
Cb

≥ 15 °
1.04
0.023
1.05
0.021
1.00
0.023
≥ 30 °
1.08
0.044
1.11
0.046
1.17
0.048
≥ 45 °
1.13
0.073
1.17
0.071
1.27
0.075
≥ 60 °
1.17
0.094
1.23
0.096
1.37
0.10
≥ 90 °
1.27
0.15
1.37
0.15
1.6
0.17
≥ 180 °
1.6
0.33
1.88
0.37
2.57
0.44
After getting value FC from Table FC, please contrast it with the curved angle of the conveyor, and you can get value Ca and value Cb.
